Bunded Tanks
Portable Fuel Storage Solutions
Atmei is expanding our product range with innovative portable fuel storage systems designed for flexibility, compliance, and rapid deployment. From compact ISO containerized units to large-capacity mobile bunded tanks, our solutions provide secure fuel storage for remote sites, temporary operations, and locations requiring immediate fuel infrastructure.
ISO Containerized Fuel Tank Systems
Self-contained fuel storage and dispensing solutions built into standard shipping containers for maximum portability and security.
23m³ ISO Containerized Tank
High-capacity portable fuel storage ideal for large-scale mining operations, construction sites, and remote industrial facilities.
14m³ ISO Containerized Tank
Mid-range solution perfect for medium-sized operations, exploration sites, and temporary fuel depots.
9m³ ISO Containerized Tank
Compact fuel storage for smaller sites, emergency backup fuel supply, and mobile refuelling operations.
Standard Features Include:
Gorman Rupp Pump
High-performance fuel transfer system
LC Flow Meter
Accurate fuel measurement and inventory control
25mm LDV Nozzle
Efficient vehicle refuelling
6m Rubber Hose
Heavy-duty dispensing hose
3m Converted Container
Weather-protected equipment housing
Sliding Front Door
Easy equipment access
Ladders
Safe tank access
Camlock Filler Points
Spill-free fuel deliveries
Pressure Relief Valve
Tank safety system
Fire Extinguisher
Emergency response equipment
Drip Trays
Spill containment during dispensing
Lifting Lugs
Crane handling and transportation
Mobile Steel Bunded Tank Systems
110m³ Mobile Steel Bunded Tank
Large-capacity, self-bunded fuel storage tanks mounted on structural steel frames for transport and relocation as operational needs change.
Capacity Specifications:
Max Tank Capacity: 121m³
Working Tank Capacity: 110m³
Overfill Level: 2870mm
Tank Features:
Lifting Lugs for crane handling
Ladder (Optional)
100mm Ø Inlet & Outlet connections
50mm Ø Drain Outlet
2 x Fire Extinguishers
Dip Hatch & Vent
Drain Valve
Dimensions:
Structure Length: 15m
Tank Cylindrical Length: 13.2m
Steel Structure Material:
100mm x 100mm x 3mm Square Tube
100 x 50 I-Beam Sections
5 x Tank Cradles for secure mounting
3mm MS Shell Plate (Steel Bund)
Pump Bund c/w Sliding Door
2 x 600mm Diameter Manholes
2 x Pump Bund Air Vents
Dimensions:
Structure Length: 18.5m
Tank Cylindrical Length: 16.47m
82m³ Mobile Steel Bunded Tank
Capacity Specifications:
Max Tank Capacity: 83.5m³
Working Tank Capacity: 82m³
Overfill Level: 2680mm
Tank Features:
Lifting Lugs for crane handling
Ladder (Optional)
100mm Ø Inlet & Outlet connections
50mm Ø Drain Outlet
2 x Fire Extinguishers
Dip Hatch & Vent
Drain Valve
Steel Structure Material:
100mm x 100mm x 3mm Square Tube
100 x 50 I-Beam Sections
3 x Tank Cradles for secure mounting
3mm MS Shell Plate (Steel Bund)
Pump Bund c/w Sliding Door
2 x 600mm Diameter Manholes
Air Vents
Dimensions:
Structure Length: 15m
Tank Cylindrical Length: 13.2m
30m³ Mobile Steel Bunded Tank
Technical Specifications:
Tank Contents: Diesel
Designed To: UL142, ULC S601
Built To: UL142, ULC S601
Plate Thickness: 6mm
Gross Volume: 30,901L
Hydraulic Test Pressure: Gross level + 150mm
Safe Fill Level: 29,350L
N.D.T.: Refer Logitank fabrication & assembly plan
Total Mass: 7,837kg
Compliance:
UL142 and ULC S601 certified for North American markets and international operations requiring these standards.
12m³ Mobile Steel Bunded Tank (T-Cube10)
Technical Specifications:
Title: T-Cube10 Self Bunded Tank Fuel Storage
Tank Contents: Diesel
Designed To: AS1940
Built To: AS1692, Category 3
Corrosion Allowance: 0mm
Gross Volume: 11,500L
Hydraulic Test Pressure: Gross level + 150mm
Safe Fill Level: 9,550L
N.D.T.: Refer fabrication & assembly plan
Weight: 4,547.29kg
Total Mass: 4,552kg
Compliance:
AS1940 and AS1692 certified for Australian markets and operations requiring Australian standards.
Advantages of Portable Fuel Storage
Rapid Deployment:
Plug-and-play fuel storage solutions operational within hours of delivery, eliminating lengthy construction timelines.
Mobility and Flexibility:
Easily transported and relocated as project requirements change. ISO containers by truck, rail, or ship; mobile bunded tanks by specialized transport.
Self-Contained Design:
Built-in secondary containment (bunding) meets environmental protection requirements without additional civil works.
Multiple Compliance Standards:
Available with UL142, ULC S601, AS1940, and AS1692 certifications to meet regional and international requirements.
Structural Integrity:
Heavy-duty steel construction with engineered support structures designed for transport and long-term field use.
Security:
Lockable pump bunds and robust construction protect fuel and equipment from theft and vandalism in remote locations.
Cost-Effective:
Lower capital investment compared to permanent fuel infrastructure. Ideal for temporary projects, phased operations, or asset flexibility.
Ideal Applications
Mining Operations
Remote exploration sites, temporary mining camps, and mobile equipment refuelling
Construction Projects
Temporary fuel storage for earthmoving equipment and construction machinery
Remote Industrial Sites
Fuel infrastructure for locations without existing facilities
Emergency Response
Rapid deployment fuel supply for disaster relief operations
Agricultural Operations
Seasonal fuel storage for harvesting equipment and farm machinery
Oil & Gas Industry
Exploration sites, pipeline construction, and remote well operations
Military and Defense
Mobile fuel logistics for field operations and training exercises
Event Management
Temporary generator fuel supply for large events
Marine and Port Operations
Dockside fuel storage and boat refuelling facilities
Design and Manufacturing Standards
All portable fuel storage systems are designed and manufactured to meet:
ISO 1496-1 shipping container standards (ISO tanks)
UL142 and ULC S601 standards (North American compliance)
AS1940 and AS1692 standards (Australian compliance)
Local fuel storage regulations
Environmental protection requirements
Occupational health and safety standards
Transport and Logistics:
Standard ISO container footprint (ISO tanks)
Engineered lifting points for safe crane handling
Road-legal dimensions for truck transport (where applicable)
Structural design for multiple relocations
Atmei’s Integrated Fuel Solutions
These portable systems complement our existing capabilities:
Fuel Management Integration
Can be fitted with electronic fuel management systems for remote monitoring and access control
Electrical Installation
Powered dispensing equipment installed by registered electricians
Site Preparation
Foundation works and leveling where required
Delivery and Installation
Complete logistics, positioning, and commissioning services
Dispensing Equipment
Optional pump, meter, and nozzle packages for turnkey refuelling solutions
Maintenance Support
Ongoing service contracts available for all portable fuel systems
Coming Soon
Atmei is finalizing specifications and preparing to launch our comprehensive portable fuel storage range. These innovative solutions will provide our clients with flexible, compliant fuel storage options for diverse operational requirements across Africa and international markets.
Contact us to register your interest and be among the first to benefit from these versatile fuel storage solutions.
